LRY-330/450 Stacked Flexographic Presses

Home > Products > Presses

Product Introduction

Print this page Send email Product Inquiry

Performance and characteristics

■ The main motor adopts imported inverter to govern a stepples speed adjustment.
■ The printing units are all equipped with a group of infrared dryers respectively .
■ Each IR dryer device of printing unit is interchangeable to UV dryer.
■ Feeding and rewinding are controlled through magnetic particle brake and clutch (Japanese Mitsubishi auto tension controller).
■ Unwinder and rewinder adopt air core holder.
■ Three unit rotary cut with stand-roller make, multi-cut can be processed.
■ Adopt ceramic anliox roller which offers durability, wear resistance and corrosion resistance, also is more efficient on production by reducing the times of changing rollers.
■ The printing unit can register in 360 degrees. Each printing unit can be independently geared and loosen to have rest of units continue to printing.
■ The inking roller will be automatically off impression when press stop and rotate at lower speed in order to keep the ink from being drying.
■ Paper unwind, printing, UV vanish laminating, rotary diecutting, waste removal and rewinding can be processed in one pass.
■ LRY-330/450 is characterized by wide application, fast printing speed and high economic efficiency and ink pullution free. It is an ideal printing machine for the business form, tag and high end pressure sensitive label.

Optionals

1、Single stacker

2、UV curing unit

3、Machine color

4、Cold foil

Technical Specification

Model	LRY-330	LRY-450
Max. Web Width	330mm	450mm
Max. Printing Width	320mm	440mm
Printing Repeat	180mm-380mm/min	180mm-380mm/min
Color	2～6	2～6
Thickness of Substrate	0.1～0.3mm	0.1～0.3mm
Machine Speed	10m-80m/min	10m-80m/min
Max. Unwind Diameter	650mm	650mm
Max. Rewind Diameter	650mm	650mm
Rotarlr-cutting Stations	3	3
Main Motor Capacity	2.2kw	2.2kw
Main Power	380V/AC 3 phase 50HZ	380V/AC 3 phase 50HZ
Overall Dimension(LxWxH)	2420x1020x2740mm	2420x1020x 2740mm
Machine Weight	2500kg /5 corlors	3000kg /5 corlors

Notes: With the viriation of the length to be printed, machine speed should be changed.

*lts overall dimension and manufacturing Process are subject to change without further notice.
